Solar traffic warning light

Solar traffic warning light
Solar traffic warning light
Solar traffic warning lightSolar traffic warning lightSolar traffic warning light
CategoriesSolar Traffic Warning Light
AlbumView larger image
BrandXiangxu Traffic
Place of OriginHunan, China (Mainland)
Brand NameXiangxu
Normal life of led≥100000 hours
ApplicationRoadway Safety Signs
Brightness of one led>4000mcd
Housing MaterialPC & metal gripping rim
Update Time2020-03-30
Detail Information

Product parameters

Housing Material PC & metal gripping rim Strobe mode Strobe
Solar panel 18V, 10W single crystalline silicon solar cell, battery life≥15 years Flash frequency 2/3Hz, 40 times/min, can be customized
Battery 12V, 6AH rechargeable lithium battery(optional) Duty Ratio 1/3
Shape&size Φ300mm ,Φ400mm  Visual range ≥1000m (at night)
Led ColorYellow lamp 95 pieces,Yellow lamp 126 piecesBrightness of one led>4000mcd
Size350*350*150mm,450*450*250mmWarranty12 months, from date of sale, providing not damaged by the user
Wavelength of led590~595nm(yellow), 625±5nm(red)Working timecan work over 200 hours or 8 rainy days after fully charged
Normal life of led≥100000 hoursIP Grade>IP54
Rate of system≤4WStandardGB14887-2003, GA/T743-2007 China, can be customized
Work mode24hrs/day or light control (by switch)

Product display

Solar traffic warning lightSolar traffic warning lightSolar traffic warning light


1.Simple to install. No need external power, no need wiring.

2.Energy saving. Low-power, solar cell, low cost

3.High light: Using import EPISTAR chip from TaiWan, high light and slow light decay.

4.Sturdy and durable. PC & Aluminum Cover, shock resistance, anti-aging, anti-corrosion

5.Stable performance. Use America ATMEL single ship to protect circuit

6.Long service life. Led ≥100000 hours, solar cell ≥15 years

7.Long working time.It can work over 200 hours or 8 rainy days after fully charged

Smart controller:

1.Defense of the charge protection. prevent electricity of battery to solar panel

2.Overcharge protection. prevent solar panel to overcharge battery

3.Overcharge protection. prevent a overcharge with the battery

4.Overload protection. it will turn off by itself when the electricity reach a 1.5 times of normal, and then work again abo

ut 1~2 min later

5.Temperature correction. it will modify the charge and discharge when there is a change of the temperatur

e the battery

6.Recovery Interval: avoid its work shaking by the automatic-restoration characteristic of battery.

7.Other protection. lightning protection, prevent the reverse connection etc
